Description
Basic Info.
| Specification | customer size |
| Trademark | Clean-Link Filtration |
| Origin | China |
| HS Code | 59119 |
| Production Capacity | 500, 000 Pics/Year |
Product Description
Foldaway paper frame filter meshProduct advantages
1.The filtration material is made from non-woven fabrics, and the synthetic fiber. It has the advantage of the large dust holding capacity, the low pressure loss in the initial period and lager air flow.2.The filtration material compounds with the material net, and is designed into the foldaway, which will provide the current air with the largest filtration area, 5 times' filtration area as the common plane mesh. Paper frame and metal frame are available, which is convenient for replace, less purchasing expense.3.The moisture-proof: 100%;4.Heat resistance: 80ºC;5.The rank of the filtration: G4.F5.F6.F7.F8.
Product Description
1.Large dust holding capacity
2.The low pressure loss in the initial period
3.Lager air flow
Using:
Pre-filter for the air-condition filtration system. It can lengthen the working life of the middle and high efficiency filter.
Note: Other specifications are available on request.
Normal size | Actual size W*H*W(mm) | Rated air flow(m³/h) | ||
1.5m/s | 2.5m/s | 3.0m/s | ||
24*24*1 | 595*595*22 | 2040 | 3400 | - |
20*24*1 | 495*595*22 | 1785 | 2975 | - |
20*20*1 | 495*495*22 | 1445 | 2380 | - |
12*24*1 | 287*595*22 | 1020 | 1700 | - |
24*24*2 | 595*595*44 | 2040 | 3400 | 4250 |
20*24*2 | 495*595*44 | 1700 | 2805 | 3570 |
20*20*2 | 495*495*44 | 1445 | 2380 | 2975 |
16*24*2 | 390*595*44 | 1445 | 2380 | 2675 |
16*20*2 | 390*495*44 | 1105 | 1870 | 2380 |
12*24*2 | 287*595*44 | 1020 | 1700 | 2125 |
24*24*4 | 595*595*90 | 2040 | 3400 | 4250 |
20*20*4 | 495*495*90 | 1455 | 2380 | 2975 |
12*24*4 | 287*595*90 | 1020 | 1700 | 2125 |
Related Products
Production Application
Pre-filtration and second filtration for the ventilation system of the air condition;
The filtration for entering or returning the air in the clean room.
Company Information
Exhibition & Certificate
Why Us?
1. We have specialized in the export of air filters for over 13 years.
2. We have our own factory and brand.
3. We provide OEM and ODM service ,sample production and service according to your demand
4. The dimension can be customized.
5. The products have passed ISO90012008 and SGS certification.
6. With independent R&D and design capablities.
